<Project Sdk="Microsoft.NET.Sdk.Web">

	<PropertyGroup>
		<TargetFramework>net6.0</TargetFramework>
		<Nullable>enable</Nullable>
		<ImplicitUsings>enable</ImplicitUsings>
	</PropertyGroup>

	<ItemGroup>
		<PackageReference Include="NLog.Web.AspNetCore" Version="5.*" />
		<PackageReference Include="NLog" Version="5.*" />
	</ItemGroup>

</Project>

install NLog.Web.AspNetCore (latest version) using NuGet Package Manager

using BPX.Website.Models;
using Microsoft.AspNetCore.Diagnostics;
using Microsoft.AspNetCore.Mvc;

namespace BPX.Website.Controllers
{
    public class ExceptionController : BaseController<ExceptionController>
    {
        public ExceptionController(ILogger<ExceptionController> logger) : base(logger)
        {
        }

        [ResponseCache(Duration = 0, Location = ResponseCacheLocation.None, NoStore = true)]
        public IActionResult Index(int? statusCode = null)
        {
            string errorStatusCode = string.Empty;
            string errorMessage = string.Empty;
            string errorURL = string.Empty;

            if (statusCode != null)
            {
                var statusCodeReExecuteFeature = HttpContext.Features.Get<IStatusCodeReExecuteFeature>();

                if (statusCodeReExecuteFeature is not null)
                {
                    errorURL = string.Join(statusCodeReExecuteFeature.OriginalPathBase,
                                            statusCodeReExecuteFeature.OriginalPath,
                                            statusCodeReExecuteFeature.OriginalQueryString);
                }

                switch (statusCode.Value)
                {
                    // 400 Bad Request
                    case 400:
                        errorStatusCode = statusCode.Value.ToString() + " Bad Request";
                        errorMessage = string.Join("Your request is not properly formed: ", errorURL);
                        break;

                    // 401 Unauthorized
                    case 401:
                        errorStatusCode = statusCode.Value.ToString() + " Unauthorized";
                        errorMessage = string.Join("The page you requested is no authorized: ", errorURL);
                        break;

                    // 403 Forbidden
                    case 403:
                        errorStatusCode = statusCode.Value.ToString() + " Forbidden";
                        errorMessage = string.Join("The page you requested is forbidden: ", errorURL);
                        break;

                    // 404 Not Found
                    case 404:
                        errorStatusCode = statusCode.Value.ToString() + " Not Found";
                        errorMessage = string.Join("The page you requested is not found: ", errorURL);
                        break;

                    // 405 Method Not Allowed
                    case 405:
                        errorStatusCode = statusCode.Value.ToString() + " Method Not Allowed";
                        errorMessage = string.Join("The method you requested is not allowed: ", errorURL);
                        break;
                }

                // code to log the exception
                logger.Log(LogLevel.Error, errorStatusCode + Environment.NewLine + errorMessage + Environment.NewLine);
            }

            return View(new ErrorVM { ErrorStatusCode = errorStatusCode, ErrorMessage = errorMessage });
        }

        [ResponseCache(Duration = 0, Location = ResponseCacheLocation.None, NoStore = true)]
        public IActionResult Error()
        {
            string errorMessage = string.Empty;
            var exceptionFeature = HttpContext.Features.Get<IExceptionHandlerPathFeature>();

            if (exceptionFeature != null)
            {
                // exception data from IExceptionHandlerPathFeature
                errorMessage = exceptionFeature.Error.Message;

                // code to log the exception
                logger.Log(LogLevel.Error, exceptionFeature.Path + Environment.NewLine + exceptionFeature.Error.Message + Environment.NewLine + exceptionFeature.Error.StackTrace);
            }

            return View(new ErrorVM { ErrorMessage = errorMessage });
        }
    }
}

{
  "Logging": {
    "LogLevel": {
      "Default": "Trace",
      "Microsoft": "Warning",
      "Microsoft.Hosting.Lifetime": "Information"
    }
  },
  "AllowedHosts": "*"
}

<?xml version="1.0" encoding="utf-8" ?>
<nlog xmlns="http://www.nlog-project.org/schemas/NLog.xsd"
      xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
      autoReload="true"
      internalLogLevel="Info"
      internalLogFile="c:\temp\internal-nlog-AspNetCore.txt">

	<!-- enable asp.net core layout renderers -->
	<extensions>
		<add assembly="NLog.Web.AspNetCore"/>
	</extensions>

	<!-- the targets to write to -->
	<targets>
		<!-- File Target for all log messages with basic details -->
		<target xsi:type="File" name="allfile" fileName="c:\temp\nlog-AspNetCore-all-${shortdate}.log"
				layout="${longdate}|${event-properties:item=EventId:whenEmpty=0}|${level:uppercase=true}|${logger}|${message} ${exception:format=tostring}" />

		<!-- File Target for own log messages with extra web details using some ASP.NET core renderers -->
		<target xsi:type="File" name="ownFile-web" fileName="c:\temp\nlog-AspNetCore-own-${shortdate}.log"
				layout="${longdate}|${event-properties:item=EventId:whenEmpty=0}|${level:uppercase=true}|${logger}|${message} ${exception:format=tostring}|url: ${aspnet-request-url}|action: ${aspnet-mvc-action}|${callsite}" />

		<!-- Console Target for hosting lifetime messages to improve Docker / Visual Studio startup detection -->
		<target xsi:type="Console" name="lifetimeConsole" layout="${MicrosoftConsoleLayout}" />
	</targets>

	<!-- rules to map from logger name to target -->
	<rules>
		<logger name="System.*" finalMinLevel="Warn" />
		<logger name="Microsoft.*" finalMinLevel="Warn" />
		<logger name="Microsoft.Hosting.Lifetime*" finalMinLevel="Info" />
		<logger name="*" minlevel="Trace" writeTo="ownFile-web" />
	</rules>
</nlog>

using NLog;
using NLog.Web;

var logger = NLog.LogManager.Setup().LoadConfigurationFromAppSettings().GetCurrentClassLogger();
logger.Debug("init main");

try
{
    var builder = WebApplication.CreateBuilder(args);

    // Add services to the container.
    builder.Services.AddControllersWithViews();

    // NLog: Setup NLog for Dependency injection
    builder.Logging.ClearProviders();
    builder.Host.UseNLog();

    var app = builder.Build();

    // Configure the HTTP request pipeline.
    app.UseExceptionHandler("/Exception/Error");
    app.UseStatusCodePagesWithReExecute("/Exception/Index", "?statusCode={0}");

    app.UseStaticFiles();

    app.UseRouting();

    app.UseAuthorization();

    app.MapControllerRoute(
        name: "default",
        pattern: "{controller=Home}/{action=Index}/{id?}");

    app.Run();
}
catch (Exception exception)
{
    // NLog: catch setup errors
    logger.Error(exception, "Stopped program because of exception");
    throw;
}
finally
{
    // Ensure to flush and stop internal timers/threads before application-exit (Avoid segmentation fault on Linux)
    NLog.LogManager.Shutdown();
}
